Hydranautics Membranes

Membranes

Standard Features

  • High Rejection
  • Sea Water Membranes
  • LFC Membranes for Low Fouling
  • SanRO Membranes for Sanitary or Full Fit

ESPA

Test Conditions

The stated performance is initial (data taken after 30 minutes of operation), based on the following conditions:
NaCl Solution, PPM * 1500
Applied Pressure **, psig (MPa) 150 psi (1.05)
Operating Temperature, °F (°C) 77° (25°)
Permeate Recovery 15%
pH Range 6.5-7.0
*ESPA4 NaCl Solution tested at 500 PPM
**ESPA4 tested at 100 psig
Hydranautics ESPA
Hydranautics Membranes
ESPA Low Energy/High Flow Tap & Brackish Water Thin Film Membranes
CPA High Rejection Tap & Brackish Water Thin Film Membranes
SWC Seawater Membranes
LFC Low Fouling Membranes
ESNA Nanofiltration Membranes

Application Data

Maximum Applied Pressure, psig (MPa) 600 (4.14)
Maximum Feed Flow, GPM (m3/h) 4040-16(3.6), 8-inch-75(17.0)
Maximum Operating Temperature, °F (°C) 113° (45°)
Feedwater pH Range* 3.0-10.0
Maximum Feedwater Turbidity, NTU 1.0
Maximum Feedwater SDI (15 mins) 5.0
Maximum Chlorine Concentration, PPM <0.1
Maximum Ratio of Concentrate to Permeate Flow for Any Element 5:1
Maximum Pressure Drop for Each Element, psig 10

Hydranautics High Rejection
Model Number Description Permeate
Flow Rate
(GPD)		 Nom. Salt Rej., %
ESPA-1812 1.8"x12" FRP 75 99.0 Download
ESPA-2514 2.5"x14" FRP 250 99.4 Download
ESPA-2521 2.5"x21" FRP 350 99.4 Download
ESPA-2540 2.5"x40" FRP 750 99.4 Download
ESPA-4014 4"x14" FRP 500 99.4 Download
ESPA-4021 4"x21" FRP 1,000 99.4 Download
ESPA-4611 4.6"x11" FRP 930 99.4 Download
ESPA-4641 4.6"x41" FRP 3,600 99.4 Download
ESPA1-4040 4"x40" FRP 2,600 99.3 Download
ESPA2-4040 4"x40" FRP 1,900 99.6 Download
ESPA3-4040 4"x40" FRP 3,000 98.5 Download
ESPA4-4040 4"x40" FRP 2,500 99.2 Download
ESPA2-LD-4040 4"x40" FRP 3,600 99.4 Download
ESPA1 8"x40" FRP 12,000 99.3 Download
ESPA2 8"x40" FRP 9,000 99.6 Download
ESPA2+ 8"x40" FRP 9,000 99.6 Download
ESPA3 8"x40" FRP 14,000 98.5 Download
ESPA4 8"x40" FRP 12,000 99.2 Download
ESPAB 8"x40" FRP 8,600 99.2 Download
ESPA2 MAX 8"x40" FRP 12,000 99.6 Download
ESPA2-LD 8"x40" FRP 10,000 99.6 Download
ESPA4-LD 8"x40" FRP 12,000 99.2 Download
ESPAB MAX 8"x40" FRP 9,000 99.3 Download
ESPA4 MAX 8"x40" FRP 13,200 99.2 Download
ESPA2 1640 16"x40" FRP 41,000 99.6 Download
ESPAB 1640 16"x40" FRP 37,000 99.3 Download

CPA

Test Conditions

The stated performance is initial (data taken after 30 minutes of operation), based on the following conditions:
NaCl Solution, PPM 1500
Applied Pressure, psig (MPa) 225 psi (1.55)
Operating Temperature, °F (°C) 77° (25°)
Permeate Recovery 15%
pH Range 6.5-7.0

Application Data
Maximum Applied Pressure, psig (MPa) 600 (4.14)
Maximum Feed Flow, GPM (m3/h) 4040-16(3.6), 8-inch-75(17.0)
Maximum Operating Temperature, °F (°C) 113° (45°)
Feedwater pH Range* 3.0-10.0
Maximum Feedwater Turbidity, NTU 1.0
Maximum Feedwater SDI (15 mins) 5.0
Maximum Chlorine Concentration, PPM <0.1
Maximum Ratio of Concentrate to Permeate Flow for Any Element 5:1
Maximum Pressure Drop for Each Element, psig 10

Model Number Description Permeate
Flow Rate
(GPD)		 Nom. Salt Rej., %
CPA2-4040 4"x40" FRP 2,250 99.5 Download
CPA5-LD-4040 4"x40" FRP 2,100 99.7 Download
CPA2 8"x40" FRP 10,000 99.7 Download
CPA3 8"x40" FRP 11,000 99.7 Download
CPA4 8"x40" FRP 6,000 99.7 Download
CPA5-LD 8"x40" FRP 11,000 99.7 Download
CPA5 MAX 8"x40" FRP 12,000 99.7 Download

Typical CPA2 systems show stable performance over element lifetime. Membranes are durable, cleanable and reliable or a wide range of operating and feedwater conditions.

Hydranautics Sea Water Membranes
Model Number Description Permeate
Flow Rate
(GPD)
SWC-2514 2.5"x14" FRP 110 Download
SWC-2521 2.5"x21" FRP 220 Download
SWC-2540 2.5"x40" FRP 520 Download
SWC-4014 4"x14" FRP 370 Download
SWC-4021 4"x21" FRP 640 Download
SWC1-4040 4"x40" FRP 1,200 Download
SWC5-4040 4"X40" FRP 1,900 Download
SWC5-LD-4040 4"X40" FRP 1,750 Download
SWC3+ 8"x40" FRP 7,000 Download
SWC4+ 8"x40" FRP 6,500 Download
SWC4B MAX 8"x40" FRP 7,200 Download
SWC4 MAX 8"x40" FRP 7,200 Download
SWC4B 8"x40" FRP 6,500 Download
SWC5 8"x40" FRP 9,000 Download
SWC5 MAX 8"x40" FRP 9,900 Download
SWC5-LD 8"x40" FRP 9,000 Download
SWC6 8"x40" FRP 6,000-12,000 Download
SWC6-4040 8"x40" FRP 1,250-2500 Download
SWC6 MAX 8"x40" FRP 6,600-13,200 Download
SWC4 1640 16"x40" FRP 27,600 Download
SWC5 1640 16"x40" FRP 36,000 Download

Hydranautics LFC Membranes for Low Fouling

Model Number Description Permeate
Flow Rate
(GPD)
LFC3-LD-4040 4"x40" FRP 2,100 Download
LFC3 8"x40" FRP 9,500 Download
LFC3-LD 8"x40" FRP 11,000 Download

Hydranautics SanRO Membranes for Sanitary or Full Fit

Model Number Description Permeate
Flow Rate
(GPD)
SanRO CPA3-8 8"x40" FRP 10,500 Download
SanRO HS-8 8"x40" FRP 8,800 Download
SanRO HS2-8 8"x40" FRP 14,000 Download
SanRO HS-4 4"x40" FRP 2,200 Download
SanRO HS2-4 4"x40" FRP 2,800 Download

Hydranautics ESNA Membranes for Nano Filtration

Model Number Description Permeate
Flow Rate
(GPD)
ESNA1-LF2 8"x40" FRP 8,800 Download
ESNA1-LF 8"x40" FRP 8,200 Download
ESNA1-LF-LD 8"x40" FRP 8,200 Download
ESNA1-LF2-LD 8"x40" FRP 10,500 Download
ESNA1-LF-4040 4"x40" FRP 1,742 Download

Hydranautics HYDRAcap Membranes for Ultrafiltration Filtration

Model Number Description Filtrate
HYDRAcap 40 HYDRAcap UF membrane 40" 7-17 gpd Download
HYDRAcap 40-LD HYDRAcap UF membrane 40” LD 4.5-11 gpd Download
HYDRAcap 60 HYDRAcap UF membrane 60” 10.5-26 gpd Download
HYDRAcap 60-LD HYDRAcap UF membrane 60” LD 7-17 gpd Download

Hydranautics Dairy RO
Model Number Description Filtrate
Dairy RO 4"x40" FRP 30 Download
Dairy UF 5K 4"x40" FRP 30 Download
Dairy UF 10K 4"x40" FRP 30 Download
Dairy RO 8"x40" FRP 80 Download
Dairy UF 5K 8"x40" FRP 80 Download
Dairy UF 10K 8"x40" FRP 80 Download

Hydranautics Sweetener
Model Number Description Filtrate
SuPRO 8.3”x38” FRP 250-350 Download
